Palazzoli 419445
Rotoswitched sockets IP66/IP67/IP69
ROTOR - ROTOSWITCHED SOCKET 125A 3P+N+E 690V 5H IP66/67/69
Terminals type: Screw - indirect clamping
Rated current: 125A
Shock resistance: IK10 according to IEC/EN 62262
Frequency: 50/60Hz
IP Protection degree: IP66/IP67
Additional IPdegree protection: IP69 - IEC 60529
Poles: 3P+N+
Clock Position: 5h
Rated operating voltage: 600-690V
Rated insulation voltage: 690 V
Manufacturing material: High resistance technopolymer
Width: -
Insulation Class: II
Operating category: AC-23A
Min conductor section: 16mm²
Max conductor section: 70mm²
Colour: Grey RAL 7046, Blue RAL 5015
Min. Amb. Temp.: -40°C
Max. Amb. Temp.: +60°C
Storage room temperature MIN: -50°C
Storage room temperature MAX: +90°C
Surface finishing: Grip in non-slip rubber
ROTOR - ROTOSWITCHED SOCKET 125A 3P+N+E 690V 5H IP66/67/69
Terminals type: Screw - indirect clamping
Rated current: 125A
Shock resistance: IK10 according to IEC/EN 62262
Frequency: 50/60Hz
IP Protection degree: IP66/IP67
Additional IPdegree protection: IP69 - IEC 60529
Poles: 3P+N+
Clock Position: 5h
Rated operating voltage: 600-690V
Rated insulation voltage: 690 V
Manufacturing material: High resistance technopolymer
Width: -
Insulation Class: II
Operating category: AC-23A
Min conductor section: 16mm²
Max conductor section: 70mm²
Colour: Grey RAL 7046, Blue RAL 5015
Min. Amb. Temp.: -40°C
Max. Amb. Temp.: +60°C
Storage room temperature MIN: -50°C
Storage room temperature MAX: +90°C
Surface finishing: Grip in non-slip rubber
